Data types

Results returned for data type polls against the API will return information in one of the formats outlined below.

Result payload

Attributes

The root structure of the data JSON payload has the following attributes.

name	type	description
`data`	list of data objects	The data retrieved from the source.
`metadata`	metadata object	Metadata related to `data`.

Metadata

Attributes

name	type	description
`count`	int	The number of objects in `data`.

File

The file data type is seen throughout the API, as it is a reference to a file that can be downloaded from the API through a files type poll.

Attributes

name	type	description
`file_id`	string	Identifier used to request the file from the API. The value is only guaranteed to be unique in the scope of the current source.
`type`	string, always `file`	Data type specifier.
`name`	string	The name of the file, excluding the extension.
`extension`	string, optional	The extension of the file if available.
`mime_type`	string, optional	The MIME type of the file if available.
`size`	int, optional	The size of the file if available.
`checksum`	string, optional	The md5 checksum if available.

Example

{
  "file_id": "abc123",
  "type": "file",
  "name": "IMG_0003",
  "extension": "jpg",
  "mime_type": "image/jpeg",
  "size": 2505426,
}


Extends file.

name	type	description
`file_id`	string	Identifier used to request the file from the API. The value is only guaranteed to be unique in the scope of the current source.
`type`	string	Always `image`.
`filename`	string	The original file name of the file. The extension in this filename need to match the extension of the file.
`file_path`	string	The path of the file relative to other files within its service. For example, the path within a backup.
`width`	int, optional	The width of the file if available.
`height`	int, optional	The height of the file if available.

Example

{
  "file_id": "abc123",
  "type": "image",
  "filename": "IMG_0003.JPG",
  "file_path": "Media/DCIM/100APPLE/IMG_0003.JPG",
  "name": "IMG_0003",
  "extension": "jpg",
  "mime_type": "image/jpeg",
  "width": 3000,
  "height": 2002,
  "size": 2505426,
}

Video

Extends file.

name	type	description
`file_id`	string	Identifier used to request the file from the API. The value is only guaranteed to be unique in the scope of the current source.
`type`	string	Always `video`.
`filename`	string	The original file name of the file. The extension in this filename need to match the extension of the file.
`file_path`	string	The path of the file relative to other files within its service. For example, the path within a backup.
`width`	int, optional	The width of the file if available.
`height`	int, optional	The height of the file if available.
`duration`	int, optional	The length of the video if available.

Example

{
  "file_id": "abc123",
  "type": "video",
  "filename": "IMG_0009.MOV",
  "file_path": "Media/DCIM/100APPLE/IMG_0009.MOV",
  "name": "IMG_0009",
  "extension": "mov",
  "mime_type": "video/quicktime",
  "width": 1920,
  "height": 1080,
  "size": 5421796,
  "duration": 9.135623
}

Video

Extends file.

name	type	description
`file_id`	string	Identifier used to request the file from the API. The value is only guaranteed to be unique in the scope of the current source.
`type`	string	Always `audio`.
`filename`	string	The original file name of the file. The extension in this filename need to match the extension of the file.
`file_path`	string	The path of the file relative to other files within its service. For example, the path within a backup.
`transcription`	string, optional	The text transcription for an audio message, if available.

Example

{
  "id": "abc123",
  "type": "audio",
  "filename": "Audio Message.caf",
  "file_path": "Library/SMS/Attachments/.../Audio Message.caf",
  "transcription": "Test voice message",
}

Audio transcriptions

When available in a backup's data, the transcription of audio messages is returned as part of the audio object. This is available on audio messages made in iOS Messages since iOS 17.

Message

Attributes

name	type	description
`id`	string	A unique identifier for the message. Use this to deduplicate returned data if necessary.
`data_type`	string, always `message`	Data type specifier.
`type`	string, optional	Used when a messaging service handles a variety of message types. For example `SMS` and `iMessage` in the case of iOS Messages.
`handle`	string	The 2nd party of the conversation, often an identifier unique to the messaging app.
`handle_name`	string, optional	Where available, a display name for the handle.
`contact`	nested contact, optional	An object referencing an iOS contact of the 2nd party of the conversation.
`conversation_id`	string	Identifier grouping messages by conversation.
`from_me`	bool	Whether the message was sent or received.
`user`	string, optional	The user of the messaging app in the case where multiple users/accounts may be using a messaging app from the device.
`text`	string	The body of the message.
`message_type`	string, optional	Classification of the message (e.g. `text`, `attachment`, `group_event`, `phone_number_change`, `poll`, `calendar_event`). Currently present on WhatsApp messages. Unrecognised database values are passed through as raw integers.
`group_event_type`	string, optional	Sub-classification for group management events. Only present when `message_type` is `group_event`. See the WhatsApp group event types section below for the full list of values.
`edits`	list of edits, optional	A list of message content edits, for apps where message editing is supported and the history persisted in backups.
`translation`	translation object, optional	Translation data if the message was translated using iOS's built-in translation feature.
`attachments`	list of files, optional	An array of `file_id` values which can be used with the `download_file` method. If the message includes no attachment, an empty array is returned.
`group`	string, optional	The name of the group at the time the message was sent.
`group_id`	string, optional	The unique identifier for the group within the context of that app. This may not be an integer, and if present, only provides information in addition to `conversation_id`.
`group_handles`	list of strings, optional	This value is `null` for person-to-person messages, and in group conversations is an array of strings representing phone numbers or iMessage email addresses.
`group_contacts`	string, optional	An array of objects referencing iOS contacts in the group.
`deleted`	bool, optional	A boolean value to indicate whether the message had been deleted.
`marked_unread`	bool, optional	Whether the user marked the message as unread, if available.
`date`	datetime	When the message was sent or received.
`date_read`	datetime, optional	When a message was first read, if available.
`date_edited`	datetime, optional	When a message was last edited, if applicable.
`date_deleted`	datetime, optional	When a message was deleted, if applicable.

translation attributes

name	type	description
`translated_text`	string	The translated text content.
`source_language`	string	The original language code (e.g., `en_US`).
`target_language`	string	The language the message was translated to (e.g., `es_ES`).

Example

{
  "id": "a1b2c3d4",
  "data_type": "message",
  "type": "SMS",
  "handle": "reincubate",
  "handle_name": "Reincubate",
  "conversation_id": "w6x7y8z9",
  "from_me": false,
  "text": "Hi from London!",
  "edits": [{
    "text": "Hi!",
    "date": "2023-06-27T10:20:00.000000Z"
  }, {
    "text": "Hi from London!",
    "date": "2023-06-27T10:21:00.000000Z"
  }],
  "attachments": [],
  "group_handles": [
    "+441234567890",
    "renate@reincubate.com"
  ],
  "deleted": false,
  "date": "2023-06-27T10:20:00.000000Z",
  "date_edited": "2023-06-27T10:21:00.000000Z"
}

Message handles and conversations

The API's data extractors support a historically broad range of source data, and will attempt to realign data that has become fragmented through app and iOS updates over time. As messaging apps add new features, they are not always careful to ensure the underlying data is migrated perfectly to the new structure. Therefore, the API must infer certain information in order to return consistent data.

One such case is for handles and conversation information returned from messaging apps, and most specifically the ios_messages.messages data module. The API will populate conversation_id with either a numeric identifier, if such information exists or can be inferred, or fallback to use the second-party's handle to set conversation_id. Therefore, using this field to tie together messages from the same chat is recommended.

Edited and deleted messages

Information on edited and deleted messages is available for ios_messages.messages for backups made from devices running iOS 16 and later. For deleted messages, information is only expected to be available while the message is still recoverable at the point the backup was made, which Apple say is 30–40 days after deletion.

For edited messages, the history of edits is returned in the edits attribute. Each edit includes the state of text and the time when the edit was committed. The text attribute of the message itself will always be the same as that of the final edit.

Translated messages

When a user translates an incoming message using iOS's built-in translation feature (available since iOS 26), the translation data is preserved in the backup and returned in the translation attribute. This includes:

The translated text content
The source language of the original message
The target language the message was translated into

Language codes follow the standard locale format (e.g., en_US for US English, es_ES for Spanish).

Note that translation data is only available for messages that were explicitly translated by the user on the device. The original message text is always returned in the text attribute.

WhatsApp message and group event types

WhatsApp messages include a message_type field classifying the message:

`message_type`	Description
`text`	Plain text message.
`attachment`	Image, video, audio, vcard, location, link, document, or gif. The specific type is in `attachments[].type`.
`group_event`	Group management event (creation, name change, member add/remove, etc.).
`phone_number_change`	User changed their phone number.
`poll`	Poll (content not yet extracted into text).
`calendar_event`	Calendar event (content not yet extracted into text).

When message_type is group_event, the group_event_type field provides sub-classification:

`group_event_type`	Description
`group_created`	A new group was created.
`group_context`	Group chat context or participant event.
`icon_changed`	Group icon was changed.
`participant_added`	A participant was added.
`participant_removed`	A participant was removed.
`participant_promoted`	A participant was promoted to admin.
`participant_change_number`	A participant changed their phone number.
`subject_changed`	Group name/subject was changed.
`description_changed`	Group or community description was changed.
`community_subgroup_linked`	A subgroup was linked to a community.
`community_subgroup_unlinked`	A subgroup was unlinked from a community.
`group_membership_permission_changed`	Who can add members was changed.
`participants_batch_added`	Multiple participants were added at once.
`community_subject_changed`	Community name was changed.
`community_description_changed`	Community description was changed.

For group events, text contains a human-readable value extracted from the event metadata. For example, a subject_changed event has the new group name as its text, and a community_subgroup_linked event has the linked subgroup's name. Unrecognised event types are passed through as raw integers.

Conversation

A conversation thread.

name	type	description
`id`	string	Item ID.
`data_type`	string, always `conversation`	Item data type ID.
`group`	optional string	Name of group.
`members`	list of `contact` items	Participants in the conversation.

Contact

contact attributes

name	type	description
`id`	string	Item ID.
`data_type`	string, always `contact`	Item data type ID.
`name`	optional string	The contact's full name.
`first_name`	optional string	The contact's first name.
`middle_name`	optional string	The contact's middle name.
`last_name`	optional string	The contact's last name.
`prefix`	optional string	The contact's name prefix.
`suffix`	optional string	The contact's name suffix.
`nickname`	optional string	The contact's nickname.
`records`	list of `contact.record` items	Contact records associated with the contact.
`organisation`	optional string	The contact's organisation name.
`department`	optional string	The contact's department within the organisation.
`jobtitle`	optional string	The contact's job title within the organisation.
`birthday`	optional date	The contact's birthday.

contact.record attribute

There are 5 types of contact record items: Phone, Email, URL, Social, and Address. They correspond to a phone number, email address, website URL, social media account handle, and street address, respectively.

The first 4 have the same attributes:

name	type	description
`type`	string	One of: `Phone`, `Email`, `URL`, `Social`.
`name`	optional string	The label associated with the record.
`value`	string	The value of the record.

The Address contact record type has additional address fields:

name	type	description
`type`	string, always `Address`	A phone number record.
`name`	optional string	The label associated with the number.
`CountryCode`	optional string	A country code.
`Country`	optional string	A country name.
`ZIP`	optional string	A zip or postal code.
`State`	optional string	A state name or abbreviation.
`City`	optional string	A city name.
`Municipality`	optional string	A municipality name.
`SubLocality`	optional string	A neighbourhood or area name.
`Street`	optional string	A street address name.

Sample data

{
  "id": "2cf6a837304d6614",
  "data_type": "contact",
  "first_name": "John",
  "middle_name": "'Gala'",
  "last_name": "Appleseed",
  "prefix": "Mr.",
  "suffix": "Jr.",
  "nickname": "John'o",
  "records": [
    {
      "type": "Phone",
      "name": "MAIN",
      "value": "1-800-MY-APPLE"
    },
    {
      "type": "Phone",
      "name": "UK",
      "value": "0800 039 1010"
    },
    {
      "type": "URL",
      "name": "HOMEPAGE",
      "value": "http://www.apple.com"
    },
    {
      "type": "URL",
      "name": "HOMEPAGE",
      "value": "http://www.apple.com/uk/"
    },
    {
      "City": "Cupertino",
      "State": "CA",
      "ZIP": "95014",
      "name": "WORK",
      "CountryCode": "US",
      "Country": "United States",
      "Street": "1 Infinite Loop",
      "type": "Address",
      "SubLocality": null,
      "Municipality": null
    }
  ],
  "organisation": "Apple Inc.",
  "department": "Marketing",
  "jobtitle": "VP Juicing",
  "birthday": "1976-04-01"
}

Call

call attributes

name	type	description
`id`	string	Item ID.
`data_type`	string, always `call`	Item data type ID.
`call_type`	string	One of: `Phone`, `FaceTime Video`, `FaceTime Audio`.
`address`	string	The second party of the call. Could be a phone number, Apple ID, or other identifier. For group calls, it will relate to the handle that started the call.
`participants`	optional list of participant objects	For group calls, a list of all call participants.
`duration`	float	The duration of the call.
`answered`	bool	Whether the call was answered.
`from_me`	bool	Whether the call was outgoing or incoming.
`video`	bool	Whether the call was a video call or not.
`date`	datetime	When the call was made.

call.participant attributes

name	type	description
`handle`	string	The handle associated with the participant, e.g. phone number, WhatsApp ID, Apple ID, etc.
`name`	optional string	The name related to the handle.
`number`	optional string	The phone number related to the handle.
`answered`	bool	Whether or not the participant answered the call.

Sample data

{
  "id": "24116c5b16b85217",
  "data_type": "call",
  "call_type": "Phone",
  "address": "07123456789",
  "participants": [{
    "handle": "01234567890",
    "number": "01234567890",
    "answered": true
  }, {
    "handle": "09876543210",
    "number": "09876543210",
    "answered": false
  }],
  "duration": 5.131359,
  "answered": true,
  "from_me": true,
  "video": false,
  "date": "2015-07-20 10:23:27.538011"
}

Event

event attributes

name	type	description
`id`	string	Item ID.
`data_type`	string, always `event`	Item data type ID.
`unique_identifier`	optional string	Item UID for deduplicating across multiple event data sources.
`calendar`	optional string	Calendar name.
`calendar_uid`	optional string	Calendar UID.
`calendar_store`	optional string	Calendar store type, i.e. `iCloud`, `Default`.
`summary`	optional string	The event summary or title.
`description`	optional string	The event description.
`start_date`	optional datetime	When the event begins.
`end_date`	optional datetime	When the event finishes.
`start_time_zone`	optional string	The timezone of `start_date`.
`end_time_zone`	optional string	The timeone of `end_date`.
`all_day`	boolean	Whether the event lasts an entire day.
`travel_time`	optional duration	The event's travel time duration.
`recurrence`	optional nested `event.recurrence`	The event's recurrence settings.
`location`	optional string	Where the event is taking place.
`start_location`	optional string	Where the event is starting from.
`attendees`	optional list of strings	Names of event attendees.
`attached_url`	optional string	A URL associated with the event.
`creation_date`	optional datetime	When the event was created. Not set if default calendar entry, such as public holidays.

event.recurrence attributes

name	type	description
`interval`	integer	The count of `repeat` to recurr at, i.e. 1 Yearly (once every 1 year).
`repeat`	string	One of: `OneTime`, `Daily`, `Weekly`, `Monthly`, `Yearly`.
`repeat_end_date`	optional datetime	When to stop recurring.

Sample data

{
  "id": "3",
  "unique_identifier": "f5fcf872-34f6-3f60-ba03-74d5a7a3bbbb",
  "calendar": "Home",
  "calendar_id": "477a2001537fe178d6b77cdceb8bac2e",
  "calendar_store": "Default",
  "summary": "Christmas Day",
  "description": "Bank holiday in the UK",
  "start_date": "2017-12-25T00:00:00.000000",
  "end_date": "2017-12-25T23:59:59.000000",
  "start_time_zone": None,
  "end_time_zone": None,
  "all_day": True,
  "travel_time": None,
  "recurrence": {
    "interval": 1,
    "repeat": "Yearly",
    "repeat_end_date": None,
    "specifier": ""
  },
  "location": None,
  "start_location": None,
  "attendees": ["John Appleseed"],
  "attached_url": None,
  "creation_date": None
}

Note

{
  "title": "Monday meeting:",
  "note": "Monday meeting:\n Discuss X,\n discuss Y.",
  "summary": null,
  "folder": "icloud",
  "sub_folder": "work",
  "attachments": [
    {
      "type": "image",
      "file_id": "8e22cf6e524357b4eb3da775d193072ebba9543f",
      "file_path": "Media/80DDDEAD-B33F-37B2-7219432C0359/Image.jpeg"
    }
  ],
  "creation_date": "2016-06-06 13:23:20.000000",
  "last_modified": "2016-06-07 15:21:25.000000"
}

Visit

A record of a website page visit.

Attributes

name	type	description
`data_type`	string, always `visit`	Item data type ID.
`url`	string	The URL of the page visited.
`title`	string	The visited page's title.
`date_created`	datetime	When the visit occurred.

{
  "data_type": "visit",
  "url": "https://reincubate.com/",
  "title": "Reincubate: the app data company",
  "date_created": "2020-01-01T00:00:00.000000Z"
}

A HTTP cookie.

Attributes

name	type	description
`data_type`	string, always `cookie`	Item data type ID.
`name`	string	The cookie's name.
`value`	string	The cookie's value.
`domain`	string	The cookie's domain specifier.
`path`	string	The cookie's path specifier.
`flags`	string	Any flags set on the cookie.
`creation_date`	datetime	When the cookie was created.
`expiry_date`	datetime	When the cookie expires.

{
  "data_type": "cookie",
  "name": "sample_cookies",
  "value": "sample_value",
  "domain": "reincubate.com",
  "path": "/",
  "flags": "",
  "creation_date": "2020-01-01T00:00:00.000000Z",
  "expiry_date": "2020-01-01T00:00:00.000000Z"
}

Location

Data attributes

name	type	description
`data_type`	string, always `location`	A data type identifier.
`latitude`	float	The location's latitude coordinate.
`longitude`	float	The location's longitude coordinate.
`altitude`	float	The location's altitude coordinate.
`horizontal_accuracy`	float	The horizontal accuracy for the measurement.
`vertical_accuracy`	float	The vertical accuracy for the measurement.
`position_type`	string	Identifier for the measurement method used.
`date_created`	datetime	When the measurement was made.

Sample data

{
  "data_type": "location",
  "latitude": 51.507452392689146,
  "longitude": -0.07398372304584414,
  "altitude": 0.0,
  "horizontal_accuracy": 65.0,
  "vertical_accuracy": 0.0,
  "positioning_type": "Wifi",
  "date_created": "2020-01-01T00:00:00.000000Z"
}

Voicemail

Represents a voicemail message from the device.

Attributes

name	type	description
`rowid`	int	The unique identifier for the voicemail within its database.
`filename`	string	The name of the audio file containing the voicemail.
`file_id`	string	Identifier used to request the audio file from the API.
`file_path`	string	The path of the voicemail file relative to the backup.
`date`	string	The date and time the voicemail was received (ISO 8601 format).
`token`	string	Status token for the voicemail (e.g., "Complete").
`sender`	string	The phone number of the caller who left the voicemail.
`callback_num`	string	The callback number associated with the voicemail.
`duration`	int	The duration of the voicemail in seconds.
`expiration`	string, optional	The expiration date of the voicemail (ISO 8601 format).
`trashed_date`	string or int	The date the voicemail was moved to trash, or `0` if not trashed.
`flags`	int	System flags associated with the voicemail.
`sim_slot`	string, optional	The SIM slot identifier for multi-SIM devices (e.g., "A-98ACC814-BDB0-51F8-A098-CB63A6A60E9F"). `null` for single-SIM devices or the default SIM slot.
`transcript`	string, optional	The text transcript of the voicemail, if available. Transcripts are generated by iOS for visual voicemail.

Example

{
  "rowid": 50,
  "filename": "50.amr",
  "file_id": "4ff0327d0148e7fa175a12f5a25ed7148a29de6d",
  "file_path": "Library/Voicemail/50.amr",
  "date": "2024-01-15 14:30:00.000000",
  "token": "Complete",
  "sender": "+123456789",
  "callback_num": "+123456789",
  "duration": 45,
  "expiration": "2024-02-14 14:30:00.000000",
  "trashed_date": 0,
  "flags": 3,
  "sim_slot": null,
  "transcript": "Hi, this is John. Please give me a call back when you get a chance. Thanks, bye."
}

Example (Multi-SIM device)

{
  "rowid": 28,
  "filename": "28.amr",
  "file_id": "a1b2c3d4e5f6...",
  "file_path": "Library/Voicemail/A-98ACC814-BDB0-51F8-A098-CB63A6A60E9F/28.amr",
  "date": "2024-01-15 14:30:00.000000",
  "token": "Complete",
  "sender": "+123456789",
  "callback_num": "+123456789",
  "duration": 30,
  "expiration": "2024-02-14 14:30:00.000000",
  "trashed_date": 0,
  "flags": 3,
  "sim_slot": "A-98ACC814-BDB0-51F8-A098-CB63A6A60E9F"
}

Data types

Result payload

Metadata

File


Video

Video

Audio transcriptions

Message

Message handles and conversations

Edited and deleted messages

Translated messages

WhatsApp message and group event types

Conversation

Contact

Call

Event

Note

Visit

Location

Voicemail

관련 문서

도움이 필요하신가요?
